stubble cultivator / 2,2 to 6,0 m working width
10-20 cm working depth

Features

Universal machine for processing of crop residues and before-seeding soil processing allow to work at the depth up to 20 cm.
Even distribution of organic matter on the whole working depth, perfect mixing it with the soil. Two row frame in combination with caved-in discs and roller allows easily to adjust the working depth and guarantees precise penetration.

Specifications of Maxiculteur

  • Working width 2,2 to 6,0 m
  • Three-point linkage
  • Models with working width 2,5 - 3,0 m: rigid frame
  • Models with working width 5,0 - 6,0 m: hydraulic foldable frame
  • 3-row frame construction
  • Row spacing 800 mm. Tine spacing 30 cm
  • Frame clearance 800 mm
  • Stone protection: shear screws 12 mm or spiral spring
  • Roller Ø 480 mm, standard version

Options

  • Side discs L+R, spring
  • Stone NON-STOP protection
  • Ring-tube roller Ø 600 mm + scrapers
  • Double roller Ø 400 mm

Maxiculteur / 3-row construction / rigid frame

Model

Working width

(cm)

Leveling discs

(pcs)

Tines

(pcs)

Weight

(kg)
Maxiculteur 250/8 250 4 8 1.420
Maxiculteur 300/10 300 6 10 1.620
Maxiculteur 400/13 400 8 13 1.820

Maxiculteur: hydraulic foldable frame

Mode

Working width

(cm)

Leveling discs

(pcs)

Tines

(pcs)

Weight

(kg)
Maxiculteur 500/16 500 10 16 2.410
Maxiculteur 600/18 600 12 18 2.550
